Product Details:
|
| Products Status: | Stock | Product Name: | NetEngine 8000 F1A (Enable 8*40GE+10*10GE+28*GE) |
|---|---|---|---|
| Switching Capacity: | 2.4 Tbit/s | Forwarding Performance: | 453 Mpps |
| Maximum Board Capability: | Fixed-configuration Router Does Not Support Flexible Cards | Capacity Density (G/U): | 1200 |
| Main Control Board: | Fixed-configuration Router Does Not Support Flexible Cards | SFU: | Fixed-configuration Router Does Not Support Flexible Cards |
| Power Module: | 2, 1+1 | Dimensions: | 43.6 X 442 X 420 Mm (1 U) |
| Port: | Beijing | ||
| High Light: | 453 mpps access point controller,453 mpps NetEngine access point controller,453 mpps access point controller NetEngine |
||
|
Parameters
|
NetEngine 8000 F1A
|
NetEngine 8000 M8
|
NetEngine 8000 M14
|
|
Switching Capacity
|
2.4 Tbit/s
|
2.4 Tbit/s
|
4 Tbit/s
|
|
Forwarding Performance
|
453 Mpps
|
453 Mpps
|
906 Mpps
|
|
Maximum Board Capability
|
Fixed-configuration router does not support flexible cards
|
200 Gbit/s
|
200 Gbit/s
|
|
Capacity Density (G/U)
|
1200
|
400
|
400
|
|
Main Control Board
|
Fixed-configuration router does not support flexible cards
|
2, 1:1
|
2, 1:1
|
|
SFU
|
Fixed-configuration router does not support flexible cards
|
2, 1:1
(integrated) |
2, 1:1
(integrated) |
|
Line Card
|
Fixed-configuration router does not support flexible cards
|
8(DC)
8(AC) |
14(DC)
10(AC) |
|
Power Module
|
2, 1+1
|
2, 1 + 1
|
2, 1 + 1 (DC)
4, 2 + 2 (AC) |
|
Fan Module
|
4, 3+1
|
2, 1 + 1
|
4, 3 + 1
|
|
Dimensions (H x W x D)
|
43.6 x 442 x 420 mm (1 U)
|
132.6 x 442 x 220 mm (3U)
|
222 x 442 x 220 mm (5U)
|
|
Typical Power Consumption
|
350 W
|
485 W
|
1270 W
|
|
Weight in Full Configuration
|
7.25 kg
|
16.5 kg
|
27.4 kg
|
