Product Details:
|
| Products Status: | Stock | Ports: | ≥ 48 |
|---|---|---|---|
| Transmission Rate: | 10/100/1000Mbps | Function: | LACP, SNMP, Stackable, VLAN Support, LACP, Stackable, VLAN Support |
| Communication Mode: | Full-Duplex & Half-Duplex | Switch Capacity: | 672Gbps/6.72Tbps, 672Gbps/6.72Tbps |
| Product Name: | CloudEngine S5731-S48T4X 48 Network Switch | Products Status:: | Stock |
| Fixed Ports: | 48 X 10/100/1000Base-T Ethernet Ports, 4 X 10 GE SFP+ | PoE+: | Not Supported |
| Forwarding Performance: | 125mpps | Chassis Height: | 1U |
| Chassis Weight: | 8.55kg | Dimensions (W X D X H): | 43.6x 442x 420mm |
| Port: | Beijing | ||
| High Light: | 6.72tbps network management switch,network management switch 48 gigabit,672gbps gigabit network switch |
||
|
Product Model
|
CloudEngine S5731-S24T4X
|
CloudEngine S5731-S48T4X
|
CloudEngine S5731-S24P4X
|
CloudEngine S5731-S48P4X
|
|||
|
Forwarding Performance
|
96 mpps
|
125 mpps
|
96 mpps
|
125 mpps
|
|||
|
Switching Capacity2
|
128/672 Gbit/s
|
176/672 Gbit/s
|
128/672 Gbit/s
|
176/672 Gbit/s
|
|||
|
Fixed Ports
|
24 x 10/100/1000Base-T Ethernet ports, 4 x 10 GE SFP+
|
48 x 10/100/1000Base-T Ethernet ports, 4 x 10 GE SFP+
|
24 x 10/100/1000Base-T Ethernet ports, 4 x 10 GE SFP+
|
48 x 10/100/1000Base-T Ethernet ports, 4 x 10 GE SFP+
|
|||
|
PoE+
|
Not supported
|
Not supported
|
supported
|
supported
|
|||
|
MAC Features
|
64,000 MAC entries
MAC address learning and aging Static, dynamic, and blackhole MAC address entries Packet filtering based on source MAC addresses |
|
|
|
|||
|
VLAN Features
|
4094 VLANs
Guest VLAN, voice VLAN GVRP MUX VLAN VLAN assignment based on MAC addresses, protocols, IP subnets, policies, and ports 1:1 and N:1 VLAN mapping |
|
|
|
|||
|
SVF
|
Plug-and-play SVF client
Automatic software and patch loading to clients One-click and automatic delivery of service configurations Independent client operations |
|
|
|
|||
|
VXLAN
|
VXLAN L2 and L3 gateways
Centralized and distributed gateways BGP-EVPN Configured through the NETCONF protocol |
|
|
|
|||
|
Interoperability
|
VBST (compatible with PVST/PVST+/RPVST)
LNP (similar to DTP) VCMP (similar to VTP) For detailed interoperability certifications and test reports |
|
|
|
|||
