Product Details:
|
| Private Mold: | NO | Products Status: | Stock |
|---|---|---|---|
| Product Name: | EWP-WA5320-FIT H3C Wireless AP Indoor Installation Type 802.11ac | Basic Information: | 2*GE LAN |
| Power Supply: | 802.11ac | Antenna: | Built-in |
| Product Positioning: | Indoor Installation | Working Frequency Band: | 5G |
| Modulation Mode: | MIMO-OFDM | Protection Level: | IP41 |
| Authentication Method: | Open System/shared Key | Color: | White Or Any |
| Port: | Beijing | ||
| High Light: | EWP-WA5320-C-EI-FIT WiFi Access Point,5Ghz Wireless Access Points For Business,WiFi Access Point 5Ghz |
||
|
Product Type
|
Wireless AP
|
|
|
|
|
Network standards
|
IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac wave2
|
|
|
|
|
Frequency range
|
Dual frequency (2.4GHz, 5GHz)
|
|
|
|
|
Network interface
|
2 Gigabit Ethernet ports
|
|
|
|
|
Other interfaces
|
1 Console port 1 USB port |
|
|
|
|
Antenna type
|
Built-in antenna system
|
|
|
|
|
Status indicator
|
orange, green, blue different working status display
|
|
|
|
|
Product authentication
|
Support 802.1X authentication, MAC address authentication, PSK authentication, Portal authentication, etc. |
|
|
|
|
Power supply
|
<12.95W
|
|
|
|
|
Product size
|
170×170×35mm
|
|
|
|
|
Product weight
|
0.50kg
|
|
|
|
|
Environmental standards
|
Working temperature: -10-55℃
Working humidity: 5%-95% (non-condensing) Storage temperature: -40-70℃ Storage humidity: 5%-95% (non-condensing) |
|
|
|
|
Other performance
|
Transmit power: 20dBm Adjustable power granularity: 1dBm Reset/restore factory configuration: support MTBF: >250000H |
|
|
|
|
Other features
|
Indoor installation type dual frequency Support QoS
Support Chinese SSID Support (IPv4/IPv6) |
|
|
|
|
Number of Clients
|
Maximum number of access users per radio: 256 (the actual number of users may vary due to factors such as application environment) Virtual AP (It is recommended to set up to 5 per radio frequency in actual applications): 32 |
|
|
|
|
Protection grade
|
IP41
|
|
|
|
|
Security performance
|
Support 64/128 bit WEP, dynamic WEP, TKIP, CCMP (11n recommended) encryption; support multiple key update trigger conditions to dynamically update unicast/broadcast keys Support 802.11i Support the second layer isolation of wireless users; support the isolation of wireless users based on SSID Support message filtering, MAC address filtering, broadcast storm suppression, etc.S upport/Wireless EAD Support SSID and VLAN binding Support Intelligent Wireless Service Awareness (wIAA) Support wIDS/wIPS Support management frame protection (802.11w) Support real-time spectrum protection (RTSG) |
|
|
|
|
Network management
|
SNMP V1/V2c/V3, Trap, HTTP(S), SSH, Telnet, FTP/TFTP Support management SSIDLog function Remote probe analysis |
|
|
|
