Product Details:
|
| Products Status: | Stock | Ports: | 24 |
|---|---|---|---|
| Transmission Rate: | 10/100/1000Mbps | Function: | LACP, Stackable, VLAN Support |
| Communication Mode: | Full-Duplex & Half-Duplex | Switch Capacity: | 336 Gbit/s |
| Product Name: | 5720 Series 24 Port 10G Network Switch S5720-28X-LI-24S-AC | Switching Capacity: | 336 Gbit/s |
| Forwarding Performance: | 108 Mpps | Memory (RAM):: | 512MB |
| Fixed Ports: | 24 X Ethernet 10/100/1,000 Base-T Ports, 4 X 10 Gig SFP+ Ports | Flash: | 240 MB |
| Dimensions (W X D X H):: | 442 Mm X 420 Mm X 43.6 Mm | Maximum Voltage Range: | 90 V AC To 264 V AC, 47 Hz To 63 Hz |
| MAC Address Table:: | 16k | Weight: | 3 Kg |
| Port: | Beijing | ||
| High Light: | s5720-28x-li-24s-ac 10g network switch,network switch 24 ports 1000mbps,s5720-28x-li-24s-ac network switch 24 ports |
||
|
Model
|
S5720-28X-LI-AC(DC)
S5720-28X-PWR-LI-AC S5720-28X-LI-24S-AC(DC) S5720-28X-PWR-LI-ACF |
S5720-52P-LI-AC
S5720-52P-PWR-LI-AC |
S5720-52X-LI-AC(DC)
S5720-52X-PWR-LI-AC S5720-52X-LI-48S-AC S5720-52X-PWR-LI-ACF |
||
|
Switching Capacity
|
336 Gbit/s
|
336 Gbit/s
|
336 Gbit/s
|
||
|
Forwarding Performance
|
108 Mpps
|
87 Mpps/144 Mpps
Note: The specifications, which are to the right of the slash (/), can be achieved by loading the GE to 10G electronic RTU license. |
144 Mpps
|
||
|
Fixed Ports
|
S5720-28X-LI-24S-AC(DC): 24 x Gig SFP ports, 8 of which are dual-purpose 10/100/1,000 Base-T or SFP ports, 4 x 10 Gig SFP+ ports
Others: 24 x Ethernet 10/100/1,000 Base-T ports, 4 x 10 Gig SFP+ ports |
48 x Ethernet 10/100/1,000 Base-T ports, 4 x Gig SFP ports
|
S5720-52X-LI-48S-AC: 48 x Gig SFP, 2 of which are dual-purpose 10/100/1,000 Base-T or SFP, 4 x 10 Gig SFP+
Others: 48 x Ethernet 10/100/1,000 Base-T ports, 4 x 10 Gig SFP+ ports |
||
|
MAC Address Table
|
16K MAC address entries
MAC address learning and aging Static, dynamic, and blackhole MAC address entries Packet filtering based on source MAC addresses |
|
|
||
|
VLAN
|
4,094 VLANs
Guest VLAN and voice VLAN VLAN assignment based on MAC addresses, protocols, IP subnets, policies, and ports VLAN mapping Super VLANBasic QinQ and selective QinQ |
|
|
||
|
IP Routing
|
Static routing, RIP, RIPng, OSPF, and OSPFv3
|
|
|
||
|
Interoperability
|
VBST (compatible with PVST/PVST+/RPVST)
LNP (similar to DTP) VCMP (similar to VTP) |
|
|
||
