Product Details:
|
| Type: | Optical Fibers | Use: | - |
|---|---|---|---|
| Warranty Time: | 1 | Product Name: | SFP-GE-LX-SM1310 Optical Transceiver,eSFP,GE Module(1310nm,10km,LC) |
| Fiber Mode:: | Single Mode Fiber | Wavelength:: | 1310nm |
| Transmission Distance:: | 10km | Receiver Sensitivity:: | <-23dBm |
| Operating Temperature:: | 0~70 °C | Rate:: | Types Of Interface: |
| Power Supply:: | 3.3V | Weight: | 0.03kg |
| Power Consumption: | <3W | Port: | Beijing |
| High Light: | sfp transceiver module osx010000,10km 10g sfp transceiver,10km sfp transceiver module |
||
Single Mode Fiber SFP 10G Optical Transceiver Module for Hua weii OSX010000 at 1310nm
|
Product Type
|
OSX010000
|
Fiber Mode
|
Single Mode Fiber
|
|
Types of Interface
|
LC
|
Types of Laser
|
SFP+
|
|
Operating Temperature
|
Standard 0~70°C
|
Operating Humidity
|
0%~90% RH (non condensing)
|
|
Transmission distance
|
10km
|
Transmission speed
|
10 Gbit/s
|
|
Wavelength
|
1310nm
|
Maximum receiver sensitivity
|
-12.6dBm
|
|
Receiver Sensitivity
|
<-23dBm
|
Extinction Ratio
|
>9dB
|
|
Saturated Optical Power
|
--8.2 to +0.5dBm
|
Power Consumption
|
<3W
|
|
Weight
|
0.03kg
|
Power Supply
|
+3.3V
|
|
Hot Pluggable Times
|
1 year SFP-GE-LX-SM1310
|
Average Output Power
|
-9 ~ -3dBm
|
